LRN-1610S (CCTV system)

LRN-1610S 4CH 8M H.265 NVR with PoE Switch, It’s a CCTV system having Resolution 5MP(90fps), 3MP(120fps), 2MP(2400fps),720p(480fps), D1(480fps)

Display

Network camera

Inputs Max. 16CH
Resolution 5MP ~ CIF
Protocols Wisenet, ONVIF
Decoding
Local Display HDMI: 1920×1080, 1280×720
Resolution 5MP(90fps), 3MP(120fps), 2MP(2400fps),720p(480fps), D1(480fps)
Performance
Record
Compression H.265, H.264, MJPEG
Recording Bandwidth Max. 100Mbps
Resolution 5MP ~ CIF
Mode Normal, Schedule(Continuous/Event), Event (Pre/Post), Dual track Recording
Event Trigger Alarm Input, Video Loss, Camera Event(Alarm, MD, Video Analytics, Defocus)
Event Action e-Mail, PTZ Preset, Buzzer, Monitor Out
Search & Play
Playback Bandwidth Max. 32Mbps(16CH simultaneously)
User Max. 4 Users (Local 1, Remote 3)
Simultaneous playback Max. 16CH(Network)
Max. 8CH(Local Monitor)
Fisheye Dewarping WEB / CMS / Mobile
Storage
Supported HDD Up to 6TB
HDD Slot SATA 2ea(Max. 12TB)
Backup
File backup BU/Exe(GUI), JPG/AVI(Network)
Function Multi channel(Upto 8CH) Play, Date-Time/Title display

Network

Protocol IPv4, IPv6, TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server, Client), PPPoE, SMTP, ICMP, IGMP, ARP, DNS, DDNS, uPnP, HTTPS, SNMP, ONVIF (Profile-S), SUNAPI(Server, Client)
DDNS Wisenet DDNS
Audio
Input/Output 16CH(network)
Compression G.711, G.726, AAC(16/48KHz)
Audio Communication 2-Way
Max Remote Users Search(3), Live Unicast(10), Multicast(20)
Security HTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access log
802.1X Authentication(EAP-TLS, EAP-LEAP)
Device Certificate(Hanwha Techwin Root CA)
Viewer Software SSM, Webviewer, Smart Viewer, Wisenet mobile
Support SDK/CGI(SUNAPI) for integration to 3’rd party VMS

LRN-1610S PoE Switch CCTV system

Functions

Camera Setup
Item IP address, Add profile edit, Bitrate, Compression, GOP, Quality, Camera MD setup, Wisestream, Dynamic GOV/FPS, VA Setup
Camera video setup (Simple focus, Brightness/Contrast, Flip/Mirror, IRIS, WDR, D&N, SSNR, Shutter, SSDR, DIS), Fisheye Dewarping Mode, Hallway View Setup, Camera Webpage
PTZ
Control Via GUI, Webviewer
Smart phone
Support Model iOS, Android
Protocol Support RTP, RTSP, HTTP, HTTPS, CGI(SUNAPI)
Control Live(Multi-Profile Support), Playback
Max. Remote Users Search(3), Live Unicast(10)
Redundancy
ARB Support
Easy configuration P2P(QR code)
Interface
HDMI 1EA
Ethernet RJ-45(10/100/1000BASE-T) x 1
RJ-45(PoE+) x 16
USB 2EA(Front 1, Rear 1)
Power inlet AC 1EA

System

System Control Mouse, IR remocon, Web
Language English, French, German, Italian, Spanish, Russian, Turkish, Polish, Dutch, Swedish, Czech, Portuguese, Danish, Rumanian, Serbian, Croatian, Hungarian, Greek, Norwegian, Finnish, Korean, Chinese, Japanese, Thai, Vietnamese

Environmental

Operating Temperature 0°C to +40°C(32℉ to 104℉)
Operating Humidity 20% ~ 85% RH
Electrical
Power Input 100~240VAC±10%
Power Consumption Max. 158.2W(2HDDs, PoE on)
Max. 34.6W(2HDDs, PoE off)
PoE Budget Max. 130W

Mechanical

Color / Material Black / Metal
Dimension (WxHxD) W370.0 x H44.0 x D320 mm (14.57″ x 1.73″ x 12.6″) (1U)
Weight 2.79Kg (6.15lb)
• The lastest product information / specification can be found at hanwha-security.com
• Design and specifications are subject to change without notice.
• Wisenet is the proprietary brand of Hanwha Techwin, formerly known as Samsung Techwin.

4CH 8M H.265 NVR with PoE Switch

• Up to 16CH 5MP
• H.265, H.264, MJPEG codec
• 100Mbps network camera recording
• Plug & play by 16 PoE ports
• Up to 2 SATA (12TB)
• HDMI local monitor
• P2P service (QR code connect)
