The EC650C BACnet it’s a Fire Alarm System interface is customised for use with Eaton’s fire systems and provides a BACnet interface to 3rd party systems by mapping fire system data to standard BACnet server objects. BMS systems can subscribe and synchronise to BACnet server objects that are updated each time a status change occurs anywhere in the fire system.

EC650C BACnet Fire Alarm System BACnet interface 3rd party systems

Key features

• BACnet interface for Eaton’s fire system Supports one BACnet MS/TP or BACnet/IP channel (configurable)
• BACnet/IP and BACnet/MSTP activity LED Easy to configure
• DIL rail mount
• Permits several Eaton panels to connect to 3rd party BACnet BMS system

Model: EC650C
Operating Voltage 24 VDC / VAC SELV +/- 10%, typ. 3W

Physical

  • Dimensions (H x W x D) 100mm x 107mm x 75mm
  • Ingress protection IP40 (enclosure)
  • IP20 (screw terminals)
  • Weight 359 grams (boxed)
  • 284 grams (unboxed)
  • Installation DIN rail mounted or wall mounted
  • Configuration Plug ‘n’ play
  • LON network EOL 120 Ω resistor
  • Environmental
  • Temperature Operating 0 to 50 °C
  • Storage 0 to 50 °C
  • Relative humidity range 10 – 90%
  • Technical specifications
