HCP-623H 1080p Analog HD 23x PTZ Dome Camera, it’s a CCTV system having Min. Illumination Color 0.3 Lux (1/30sec, F1.6, 50IRE) , 0.005 Lux(2sec, F1.6, 50IRE)

Product Spec


Imaging Device 1/2.8″ 2.38MP CMOS
Resolution 1920×1080
Min. Illumination Color: 0.3 Lux (1/30sec, F1.6, 50IRE) , 0.005 Lux(2sec, F1.6, 50IRE)
B/W: 0.03 Lux (1/30sec, F1.6, 50IRE), 0.0005 Lux(2sec, F1.6, 50IRE)
Color: 0.2 Lux (1/30sec, F1.6, 30IRE), 0.003 Lux(2sec, F1.6, 30IRE)
B/W: 0.01 Lux (1/30sec, F1.6, 30IRE), 0.0001 Lux(2sec, F1.6, 30IRE)
Video Out BNC(AHD), CVBS(SD, DIP connector type)


Focal Length (Zoom Ratio) 4.44 ~ 102.2mm(23x) motorized varifocal
Max. Aperture Ratio F1.6(Wide) ~ F3.63(Tele)
Angular Field of View H : 62.8° (Wide) ~ 3.14° (Tele) / V : 36.8° (Wide) ~ 1.76° (Tele)
Min. Object Distance Wide 1.5m(4.92ft), Tele 2.0m(6.56ft)
Focus Control Auto / Manual / One push
Lens Type DC Auto Iris

Pan / Tilt / Rotate

Pan Range 360° Endless
Pan Speed Preset: 700°/sec, Manual: 0.024°/sec ~200°/sec
Tilt Range 210°(-15° ~195° )
Tilt Speed Preset : 700°/sec, Manual : 0.024°/sec ~200°/sec
Preset Accuracy ±0.2°

HCP-623H 1080p Analog CCTV system


Camera Title Displayed up to 12 characters
Day & Night Auto(ICR)
Backlight Compensation BLC, HLC, WDR
Wide Dynamic Range 120dB
Digital Noise Reduction SSNRⅢ
Digital Image Stabilization Support
Defog Support
Motion Detection 1ea, rectangular zone
Privacy Masking 12ea, rectangular zones
Gain Control Low / Middle / High
White Balance ATW / AWC / Manual / Indoor / Outdoor
Electronic Shutter Speed ESC / Auto / Manual
Video Rotation Digital Flip
Analytics Motion detection, Appear/Disappear, Enter/Exit, Virtual Line
Serial Interface RS-485: Samsung-T/E, Pelco-D/P, Panasonic, Bosch, AD, GE, Vicon, Honeywell
Alarm I/O Input 4ea, Output 2ea
Alarm Triggers Analytics
Alarm Events Alarm output
Coaxial Protocol ACP(AHD Coax Protocol), CVBS : Pelco-C(Coaxitron)

Environmental & Electrical

Operating Temperature / Humidity -10°C ~ +55°C(+14°F ~ +131°F) / Less than 90% RH
Input Voltage 24VAC
Power Consumption Max 20W


Color / Material Ivory / Plastic
Product Dimensions / Weight Ø152.0×218.0mm(5.98×8.58″), 1700g(3.75 lb)
• The lastest product information / specification can be found at hanwha-security.com
• Design and specifications are subject to change without notice.
• Wisenet is the proprietary brand of Hanwha Techwin, formerly known as Samsung Techwin.

1080p Analog HD 23x PTZ Dome Camera

Key Features

Full HD (1920 x 1080, 30fps) Resolution
0.2Lux@F1.6 (Color), 0.01Lux@F1.6 (B/W)
Powerful 23x Zoom (4.44 ~ 101.2mm), Digitial 16x
Day & Night (ICR), Defog, WDR (120dB), SSNRIII
Preset : 700˚/sec, Azimuth
IP66 / IK10 (HCP-6230H), IK10 (HCP-6230 + SHP-3701H Only)
RS-485, Coax Control
