Fire Alarm System

ULMCIM-UL micro single channel input unit is a single input, soft addressed micro interface, incorporating integral short circuit isolators. It is extremely compact and therefore ideal for incorporation into other equipment. It is designed for applications requiring the monitoring of a set of normally open, volt free contacts such as sprinkler system flow switches, auxiliary panel fire/fault signals as well as non fire input signals such as flow valve open contacts, generator start up, fire door closed etc. Features and benefits • Soft addressed • Integral short circuit isolator • Single address • Suitable for monitoring: flow switches / non fire inputs / auxillary panels • Optional variant: ULMCIM-C • Quick and simple to install • No hard addressing required (plug and play) • Compact size Optional variant The ULMCIM-C is designed for use with Eaton’s pull stations and is identified by the panel as a pull station. Therefore, up to 200 can be connected to the loop (ULMCIM maximum [...]

ULMCOM-UL micro single channel output unit an extensive range of interfaces are available to support the Eaton range of UL intelligent addressable control panels, providing solutions for most design requirements. The UL single channel output unit (ULMCOM) is an extremely compact unit ideal for incorporation in to external equipment and suitable for switching low voltages (24V dc at 1A maximum). This unit incorporates a set of non latching relay contacts and is suitable for switching HVAC control circuits, plant shutdown control circuits, fire door closure etc. The ULMCOM is identified by the panel as an input / output unit, with a maximum of 20 units permitted per loop. Features and benefits • Soft addressed • Integral short circuit isolator • Single address • Non latching changeover relay contacts • Suitable for switching low volts control gear • Optional variant: ULMCOM-S • Quick and simple to install • No hard addressing required (plug and play) • Compact size Optional variant The [...]

Addressable Callpoints Addressable Callpoints have integral short circuit isolators and have a status LED fitted as standard. To simplify replacement of glass element callpoints are fitted with fast fit clip on front covers. CBG370S / CBG370WP MBG813 / MBG817 FXN501 / FXN503 Benefits and Features > Approved to EN54: Pt 11 > Convenient clip fixed front cover > One key for test and cover removal > Available as surface / flush and weatherproof (IP67) Follow Us on Facebook Contact Us

The UL pull stations, APS100 and APS200. Both the APS100 and APS200 are compatible with the Eaton UL range of intelligent addressable fire systems, and come complete with a ULMCIM-C fast response intelligent addressable input initiating unit. This UL pull station is constructed of high quality, diecast metal for long lasting performance and is designed to be fitted to a single gang back-box for flush mounting. For surface mounting a sheet metal back box (SGB32S) can be utilised. The APS100 and APS200 are painted red with raised white lettering, have a locking mechanism to prevent unauthorized reset and are complete with a UL listed fast response intelligent addressable input initiating module (ULMCIM-C) Features and benefits • Single/dual action options • Complete with Initiating module (addressable variants only) • Key reset • Corrosion resistant gold plated SPST contacts • High-gloss red enamel finish with raised white lettering • Class A, style 7 SLC • Quick and simple to install • High [...]

EC540 LON Range EC541 – TCP-IP Converter, EC542 – LON Booster The EC540 LON Range of modules includes smart switch technology, which has been tailored in these models for use with Eaton’s fire system LON network. Their purpose is to extend the distance possible when transmitting fire system data between control fire control panels; extended transmission distances are achieved via the fire system’s LON network, with a further option to convert media from LON to TCP-IP. The EC541 is suitable for applications where Eaton’s fire system data is required to be extended over TCP/IP. The EC542 LON Network Booster is the solution to interconnect multiple channels and provide an extension of the network. Key features • Extends Eaton fire system network • Plug and play • No configuration required • Simple to use Follow Us on Facebook Contact Us

EFGVS - Eaton Fire Graphical Visualisation Software is a state of the art and powerful supervision management tool for Eaton Fire addressable systems. Users can monitor, visualise in 2D and 3D, control and interrogate their systems to ensure alarms are located quickly and dealt with efficiently. Ergonomic and intuitive, EFGVS includes a comprehensive list of advanced features offering the system designer and site supervisor a very efficient tool ensuring all information and controls be available at their fingertips. Eaton fire software enables 2D floor plan visualisation, but also provides a global building 3D view. It delivers alarm information through image and sound notifications but also records all other system events and faults, allowing the generation of comprehensive reports. System control access through EFGVS can be tailored based on local regulations and user credentials. Features • Audio and visual alerts • Floor plan system visualisation • 3D idle/overview mode including mouse hover/click interaction • Sweeping animations • Programmable buttons and displays [...]
