Strobes SRL is a Fire Alarm System US having 8 to 17.5 V (12V nominal) or 16 to 33 V (24 nominal) and Wiring Gauge 12 to 18 AWG
Specifications
Candela
Selectable strobe settings of 15, 30, 75, 95, 110, 135, and 185 cd
Color: Red
DC Max Op Current
(see Data Sheet for complete current draw information)
FWR Max Op Current
(see Data Sheet for complete current draw information)
Location
Indoor
Marking
FIRE
Maximum Humidity
10 to 93% non-condensing
Mounting
Wall
Operating Temperature
32°F to 120°F (-0°C to 49°C)
Operating Voltage Range
8 to 17.5 V (12V nominal) or 16 to 33 V (24 nominal)
Series
L-Series
Voltage
Regulated 12DC/FWR or regulated 24DC/FWR
Wall Mount Dimensions
5.6"L x 4.7"W x 1.25"D (142 mm L x 119 mm W x 32 mm D)
Wiring Gauge
12 to 18 AWG
