The DH-2018P is a high-efficiency 18-Port PoE Switch designed specifically for the DirectIP™ ecosystem. For KYR Company, this switch serves as the ideal mid-range solution for connecting up to 16 IP cameras with a dedicated high-speed uplink to the NVR, ensuring stable 10/100/1000Mbps data transmission across the entire security network.

DH-2018P

DirectIP® 18-Port PoE Switch

The DH-2018P is engineered to simplify the installation of multi-camera systems. It features 16 Power over Ethernet (PoE) service ports and 2 Gigabit uplink ports, providing a reliable and organized way to manage power and data. Its plug-and-play compatibility with IDIS DirectIP NVRs makes it an essential component for KYR Company’s medium-to-large surveillance deployments.

Product Features

  • 16 Dedicated PoE Ports: Provides 10/100BASE-T connectivity and power to up to 16 IP cameras over a single Ethernet cable.

  • Dual Gigabit Uplinks: Features 2 x 10/100/1000BASE-T ports for high-speed connection to NVRs or core network switches, preventing bottlenecks.

  • Robust PoE Budget: Offers a total power budget of 140W, supporting up to 16 IEEE 802.3af (PoE) devices or 4 IEEE 802.3at (PoE+) devices for higher-power units like PTZs.

  • DirectIP™ Optimization: Designed for individual port data transmission to DirectIP NVRs, allowing for automatic device discovery and simplified management.

  • Centralized Power Control: Enables easy monitoring and management of camera power directly through the IDIS software interface.

  • Rack-Mountable Design: Standard 19-inch 1U form factor ensures easy integration into professional server racks and cabinets.

  • Reliable Performance: 7.2Gbps switching capacity and 256MB SDRAM ensure consistent data handling even under heavy surveillance traffic.

Technical Specifications

CONNECTIVITY & PERFORMANCE

  • Total Ports: 18 Ports.

  • Service Ports: 16 x RJ45 (10/100BASE-T) with PoE.

  • Uplink Ports: 2 x RJ45 (10/100/1000BASE-T).

  • Switching Capacity: 7.2 Gbps.

  • System Memory: 256MB SDRAM / 32MB Flash.

POWER OVER ETHERNET (PoE)

  • PoE Standards: IEEE 802.3af-2003 / IEEE 802.3at-2009.

  • Total PoE Budget: 140W.

  • PD Connection: Up to 16 x 802.3af devices or 4 x 802.3at devices.

GENERAL & MECHANICAL

  • Dimensions (WxHxD): 430mm x 44mm x 180mm (Standard 1U).

  • Weight: 2.05 kg (4.52 lbs).

  • Power Input: AC 100-240V, 50/60Hz.

  • Max Power Consumption: 160W (including full PoE load).

  • Approvals: FCC, CE, KC, UL, CB.
