BFR-150

The BFR-150 fingerprint reader it’s an Access Control System by RBH is available with a MIFARE smart card reader. Users will benefit from its unparalleled performance, ease-of-use, precision and fast matching speed.

This fingerprint reader features a highly accurate optical sensor with tamper switch, advanced matching algorithm and a three color LED indicator for acceptance and rejection of fingerprints.

Verification Option:

Fingerprint/Fingerprint + Card / Card

Verification Mode:

1:1 / 1:N

Verification Time:

Less Than 2.0 Seconds (1:1 Verification Mode)

Registration Time:

Less Than 3.0 Seconds

Templates:

Up to 9,500

PC to Reader / Panel to Reader:

Ethernet TCP/IP Cable / Wiegand (6 Cond. Shielded, Stranded, 18-22 AWG)

Wiegand Out:

1

Communication Speed:

Ethernet 10/100M

Integrated Reader:

MIFARE CSN

Measurements:

160 x 56.9 x 40mm

Operating Temperature / Humidity

00C-650 C/ 5%-95% RH

Rating:

IP-65

Power:

DC 9~24 V, 1A
